Quantum Flooring Solutions is the leading independent stair nosing and accessories manufacturer in the UK, with over 50 years of experience. It supplies a complete range of stair nosings, entrance mattings, flooring accessories and transitions. These can be used in conjunction with all types of floorcoverings, whether contract or domestic.

Based in Oldham in Lancashire, the company manufactures and supplies its products for use throughout the UK and Worldwide. Safety is of paramount concern, with Quantum products offering complete solutions that minimise risk to the end user.

In the UK, supplies of stair nosing profiles and entrance matting are supported by the unique Quantum Flooring Measure Service. Rapid and accurate step measurements are transmitted electronically to the flooring contractor as part of a responsive service package, saving time and money for the floor-fitter.

As part of its commitment to protect the environment and improve the manufacturing process Quantum Flooring Solutions is ISO14001 and ISO9001 accredited. A Carbon Reduction Roadmap is also available, outlining the company's sustainable practices.

Stair nosing

Q-Range Stair Nosing

The Q-Range offers a selection of 39 special profiles. This unique Stair Nosing design is suitable for installation in all categories of public and commercial buildings. The Quantum Flooring Solutions patented all-over tread, which provides a slip resistant surface from the nose to the back

edge, gives the benefit of extra safety when ascending or descending stairs. The satin etched aluminium riser surface provides the double benefit of being scratch resistant and also inhibits the potential for ‘glare’, which is one of the requirements of the latest BS 8300-2:2018 and Building Regulations* guidelines applicable to stairs in areas of

Public Access

S-Range Stair Nosing

Durable aluminium Stair Nosings designed for use in a wide range of commercial and industrial applications where slim gauge floorcoverings such as vinyl or lino are specified. Options of lipped and ramped back edge profiles are safety features which reduce the risk of tripping – useful in educational and healthcare locations.

H-Range Stair Nosing

Offering a thicker gauge than the S-Range, the H-Range of Stair Nosings is available with durable aluminium carrier channel options. They can be used in most commercial applications including offices, retail, leisure, education and healthcare. Their thicker gauge enables them to be fitted

with a wide variety of textured floorcoverings, such as carpet and carpet tiles from most leading manufacturers.

Z-Range Stair Nosing

This special range of aluminium Stair Nosings comprises a selection of popular cost-effective profiles for a wide range of commercial applications including offices, retail, leisure, education and healthcare. This range has been developed to respond to the demand for a best value solution for a competitive market place. Available with the full choice of tread colours.

QFSN Range

This selection of flexible PVC profiles can be used when a quick and/or temporary fitting of a Stair Nosing is required. They are supplied preboxed and are easily cut and trimmed on-site where they can be fitted without waiting for fully cut and drilled measured Stair Nosings. They can also be curved around gentle radii without templating, and are priced to give good value. However, they do not have the durability of the more rigid aluminium or uPVC based Stair Nosings, and are best used in light trafficked conditions, or for short term applications. When used in light

foot trafficked conditions, selected flexible PVC Stair Nosings can also offer Building Regulation best practice solutions.

EcoGlo Tread

The Ecoglo tread material option offers an innovative solution to stair safety. In areas of reduced light, Ecoglo tread will illuminate the step edge using a unique photoluminescent material. The photoluminescent strip is combined with a silicon carbide band to increase slip resistance.

The photoluminescent strip can be charged by both natural and artificial light so is suitable for both internal and external installations. See p.37 for photoluminescent charging times. More information is available at: quantumflooring.co.uk search for 'Ecoglo'.

Flooring Accessories

Capping strips & cove former

These profiles are used in conjunction with each other to allow for the floorcovering to be continued up the wall for a neat and clean finish in wet and sanitised areas. The Cove Former is installed at the junction between the wall and the floor. This creates a hidden curved support for the floorcovering as it is formed over the junction and up the wall. A Capping Strip is installed where the floorcovering ends, providing a neat and sealed finish to the installation. Capping Strips are available in flexible PVC, rigid uPVC

and also aluminium, enabling them to be fitted with a wide range of floorcovering gauges. They are available in a number of colours to complement floorcovering colour options.

Combined Cove–Capping profiles (CCF1 & CCF2) offer good value options for commonly specified finishes.

Sit-On Skirting

Installed on top of the flooring, this range of flexible skirtings offers easy to fit options to cover the join between wall and floor. Generally Sit-On Skirtings are used with hard floorcoverings such as vinyl and lino,

and typical application areas include schools and public buildings. They are available in a number of different sizes and colours

The Q60 SOC and Q100 SOC profiles are supplied in 32 m coils which enable on-site trimming and a reduction in the number of joins along a corridor length.

Set-In Skirting

Set-In Skirtings also cover up the join between floor and wall, but have the additional feature of being welded to the vinyl or lino flooring material. The sealed join ensures that they can be used in areas which are often wet through cleaning as the weld also inhibits bacterial growth.

Consequently Set–In Skirtings are typically to be found in hospitals, clinics and schools. Weld Rod in 80 m coils is a available in a range of complementary colours

Flooring Transitions

Ramp Trims

Ramp Trims are used to take the edge of an installed floorcovering down to the base residual flooring. They protect the floor material edge and reduce the risk of the junction becoming a trip hazard.

Different ramp back heights accommodate a range of floorcovering gauges. Diminishing Strips are protective edge trims which help to create a safe transition at floorcovering edges. When used underneath a flooring material they increase the gauge to match up to an adjacent thicker material or accessory.

Cover Joints

PVC Cover Joints are positioned between vinyl edges where they cover the joints in a subfloor to reduce the risk of the main floorcovering cracking or splitting. They are not a full expansion joint, but they do help to maintain and protect the floorcovering in a safe condition.

Trims

PVC Trims are single profiles that are secured to the residual floor and adjoining floorcoverings are fixed in place up to either side of the profile. The Quantum Flooring Solutions Shower Threshold is usually positioned

under the floorcovering at entrances to wet areas, providing an effective barrier which reduces the escape of surface water from the area. Surface fitting is also possible.

Dementia Friendly Transitions

Dementia Friendly Transitions provide the perfect solution for joining different floorcoverings together or as a door bar. A uPVC channel with separate tread insert are both available in a range of colours to meet the guidelines set out by the Dementia Services Development Centre (DSDC)

at Stirling University. These give specifiers the options they need to select a safe transition profile between floorcovering joints where there should be very little tonal difference. Supplied pre-drilled and taped.

LVT Transitions

LVT Transitions are available in 2 finishes: silver satin and chrome polished, to complement your LVT. They are supplied pre-drilled with countersunk screw holes.

TopClip Transitions

The TopClip range from Quantum Flooring Solutions is a two-pieceproduct suitable for use in all commercial and public situations (including hospitals and schools). TopClip can now fit across an even greater range of height differences at floorcovering joints, due to the redesigned clip-in top profiles which are securely accepted into the base sections. TopClip can now form a neat, safe and durable junction between practically any variation of different floorcoverings. The slip resistant Tops are available in 24 colours to complement any design scheme and are easy to clip-in and fit on-site, plus uPVC bases can also be curved on-site. (Please note: QTC60R Tops cannot be curved on-site.)

Tops can be replaced so that the colour can be altered as part of a refurbishment programme, or if a worn or damaged section needs to be changed without renewing the base or disrupting the fitted floorcovering.

Entrance matting

Primary Entrance Matting

Industry research has shown that 94 % of all dirt that enters a building is brought in on the soles of shoes

or by wheeled traffic. This dirt creates a health and safety issue due to the increased risks of slips, trips or

falls. By specifying the correct type of entrance matting this risk can be significantly reduced.

Quantum Flooring Solutions offers a range of Entrance Matting, which can be ordered through Quantum Distributors. A free on-site measuring service is available, QSMS, which means that once a Quantum Entrance Mat is specified, the product will be made to the correct size, and will fit when delivered to site.
